TOMEI EXHAUST MANIFOLD KIT EXPREME FA20 ZN6/ZC6 EQUAL LENGTH with TITAN EXHAUST
TOMEI EXHAUST MANIFOLD KIT EXPREME FA20 ZN6/ZC6 EQUAL LENGTH with TITAN EXHAUST
SKU:TB6010-SB03A
Couldn't load pickup availability
**PLEASE CONTACT US BEFORE ORDERING THE PARTS FOR AVAILABILITY**
Item Description
Equal length, 4-2-1 design for peak power
The FA20 boxer engine inside the Scion FR-S/Subaru BRZ can be said to be the successor to the EJ engine. At Tomei Powered, through our extensive testing, we've produced numerous EJ engine and exhaust parts. By applying our knowledge and experience of EJ engines to the ZN6/ZC6, we conducted even further tests to produce 2 new exhaust manifolds with different characteristics. Using this in conjunction with our new joint pipe, released at the same time, can yield even better results.
KIT CONTENTS
- EXHAUST MANIFOLD (1)
- GASKET (ENGINE SIDE) (2)
- GASKET (JOINT PIPE SIDE) (1)
- FLANGE BOLT (2)
- FLANGE NUT (2)
- TITAN EXHAUST BANDAGE (1)
- BANDAGE BAND (10)
- BOLT SMOOTH PASTE (1)
Includes all gaskets, nuts, bolts etc. required for installation. Titan exhaust bandage also included to protect surrounding components.
SPECIFICATIONS COMPARISON VS STOCK
OEM
| Optimized pipe lengths and angles. |
| Improved exhaust efficiency through catless design. |
| Designed to minimize heat transfer to the oil pan. |
※Joint pipe sold separately
TOMEI UNEQUAL LENGTH
TOMEI EQUAL LENGTHSTOCK
|
|
MATERIAL | LAYOUT | PIPE DIAMETER（Φ） |
PIPE THICKNESS (mm) |
FLANGE THICKNESS (mm) |
WEIGHT (kg / lbs) |
|||
| Port exit - 1st juncture |
Port exit - 1st juncture |
2nd juncture - joint pipe |
Front | Rear | |||||
| TOMEI EQUAL LENGTH |
SUS304 | 4-2-1 | 42.7 | 45.0 | 60.5 | 1.5 | 12.5 | 12.5 | 6.45 / 14.22 |
| TOMEI UNEQUAL LENGTH |
SUS304 | 4-1 | 42.7 | - | 60.5 | 1.5 | 12.5 | 12.5 | 6.85 / 15.1 |
| OEM | - | 4-2-1 | 42.7 | 45.0 | 51.2 | 1.5 | 9.0 | 10.0 | 9.2 / 20.28 |
OTHER FEATURES
Slider adjusts for the lost-wax cast collector, heat expansion and gasket thickness.
Complete with o2 sensor boss.
Lightweight, highly rigid stepless flange.
* photo may vary from actual product *
